Equipment parameter description and configuration:
Horizontal cutting method
Cutting angle 90 °
Motor power 5.5KW
Saw blade size 600 * 5.0 * 25.4mm * 120/100/80/60T
Feed motor power 0.12KW
Sawing range 205 * 410mm
The spindle speed is 2600R P.M
Mechanical dimensions 1530 * 700 * 1660mm
Required pressure 5-6kg/cm ²
Sawing accuracy ± 0.1mm
Weight 500kg
Product Features:
The GLS600 semi-automatic aluminum cutting machine is suitable for sawing various shaped non-ferrous metals, aluminum, aluminum alloys, copper, copper alloys, plastics, organic glass (acrylic), and carbon fiber materials. It is particularly suitable for precision sawing of busbars, aluminum alloy cable trays, light boxes, screens, audio panels, heat sinks, graphics cards, network cards, hard drive cases, mobile phone aluminum cases, aluminum extrusions, and various shaped materials.
1. Accurate 90 degree sawing, high precision, smooth and burr free cutting surface, high efficiency.
2. Just need a foot switch, mechanical automatic pressing, and automatic sawing are both safe and easy
3. Hidden saw blade horizontally pushes left and right for cutting, capable of cutting single or multiple materials simultaneously
4. The material pressing system is driven by precision sliding rails and controlled by air compression cylinders, with high stability in material pressing
The pressing pressure can be adjusted separately according to the material type to prevent material damage caused by heavy pressure. The pressing height, speed, and sawing speed can be set according to the size and thickness of the material.
5. The spray cooling system is used to suck out the coolant through the air control vacuum valve, and then atomize the trace coolant through compressed air and spray it to the processing area to effectively lubricate the saw blade.
The difference from ordinary semi-automatic horizontal aluminum cutting machines on the market:
This model uses precision square guide rails for all cutting, equipped with guide rail lubrication devices. The motor is matched with a synchronous belt frequency converter to control the cutting speed. The cutting linearity is good, and the low-speed and high-speed speeds are more stable. The surface smoothness and burrs of the cutting material have been greatly improved, making the blade more durable, easier to operate, and the cutting straightness tolerance lower, with a straight line error of ± 0.01mm.
